Product Details:
|
| Warranty: | 4 Years | Type: | Other |
|---|---|---|---|
| Applicable Industries: | Garment Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Home Use | Showroom Location: | None |
| Video Outgoing-inspection: | Provided | Machinery Test Report: | Provided |
| Warranty Of Core Components: | 4 Years | Core Components: | PLC |
| Condition: | New | Application: | Aluminum Foil Container Making |
| Packaging Type: | Cartons, Film | Packaging Material: | Glass, Wood |
| Automatic Grade: | Automatic | Driven Type: | Electric |
| Voltage: | 220V | Power: | 5.KW |
| Weight: | 1200 KG | Dimension(L*W*H): | 2000*1700*1800mm |
| Key Selling Points: | Easy To Operate | After-sales Service Provided: | Engineers Available To Service Machinery Overseas |
| Max. Pressure: | 630kn | Max. Material Width: | 650mm |
| Speed: | 200pcs/min | Slide Stroke: | 120-260mm |
| Mould Loading Height: | 310-480mm | Press Power: | 4 Kw |
| Feeding Machine Power: | 1.5kw | Feeding Accuracy: | +_0.1mm |
| Port: | Shanghai |
item | value |
Thickness of Raw Material | 250g/m2-600g/m2 |
Width of Raw Material | 500—600mm |
Maximun Unwinding Diameter | φ600mm |
Inner Diameter of Raw Material Roll Core | φ76mm |
Finish product | any size |
Cutting Length of Roll | any size |
Production Efficiency | more than 12000pcs/Hour |
Decoil Centering Stroke | +/-20mm |
Air Pressure | 0.6Mpa |
Magnetic Powder Brake | 50N.M |
Automatic feed jumbo | Yes |
Correction system | EPC Yes |
Mold Raw material | DC53 from Japan |
Scrap kick device | Yes |
